• Designed for tractors with 35 - 50 PTO HP.
• Short turning radius for cutting in small areas.
• 1-1/2” cutting capacity.
• Low tongue weight for smaller horsepower tractor applications.
• Unique “wing-bar” blade carrier protects the gearbox output shaft with minimal weight.
• Designed for 540 RPM PTO tractors. Equal angle fully pivoting tongue and direct acting suspension system for uneven terrain.
• Smooth decks for easy cleaning and unobstructed underside for airflow through the high volume cutting chamber.
• Provides dramatic reduction in mowing time compared to most rigid deck cutters.
• Large center section skid shoes and tapered wing shoes provide anti-scalping protection.
• Chain guards included for protection.
|Cutting Height||1-1/2” - 12”|
|Height Adjustment||Hydraulic Cylinder|
|Blade Carrier||Wing Bar|
|Blades||1/2” x 3”|
|HP Required (Min.)||35 PTO HP|
|Gearbox Rating*||160 HP Divider|
|65 HP Center & Wing|
|Output Shaft Diameter||1-9/16”|
|Blade Tip Speed (FPM)||14,504 Center/13,925 Wing|
|Cut Capacity||1-1/2” Diameter|
|Driveline Size||CAT 4 Equal Angle Main/Cat 3 Wing|
|Deck Thickness||Center: 10 Ga Bottom, 12 Ga Top|
|Wings: Double 12 Ga in high stress areas|
|Side Skirt||1/4” x 11-1/2”|
|Tire & Wheel Option||Foam Filled Used Airplane Tires or
|Wing Lift Hydraulics||Standard|
|Wing Flex (Degrees)||88° Up/25° Down|
|Safety Tow Chain||Standard|
|Safety Deflector||Chain Guard|
|Tongue Weight||748 lbs|
|Weight (Approximate)||2,750 lbs|
