More Power for Every Chore
A turbocharged, 3-cylinder, 1.9-L engine delivers increased power across the Compact Farmall C series tractor lineup. Models range from 35 to 55 hp (28-47 PTO hp) — a 5-hp increase over previous models. These engines also provide greater displacement and up to 20 percent greater torque output.
Common Rail Direct Injection
The latest fuel-injection technology offers several advantages, including improved power performance, increased efficiency and cleaner emissions.
Tier 4 B/Final Compliant
Engines use an internal Exhaust Gas Recirculation (EGR) system to meet Tier 4 B/Final requirements. A 50-hour Diesel Particulate Filter (DPF) regeneration interval helps keep your workday humming.
Transmission Options For Your Operation
Choose the standard mechanical shuttle transmission or the popular 3-range hydrostatic option:
Mechanical Shuttle Transmission
The standard shuttle transmission features 12x12 (three non synchronized ranges, four synchronized speeds) on Farmall compact models 35C and 40C, and 16x16 (four non synchronized ranges, four synchronized speeds) on Farmall compact models 45C, 50C and 55C.
A 3-range hydrostatic transmission is available on all models. An easy-to-operate, 2-pedal system, electric cruise control and infinite operating speeds makes this option a popular choice when considering operator convenience and fatigue. Simply press the forward pedal to move forward and press the reverse pedal to go in reverse. It’s an excellent choice for tasks, such as loader work and mowing, requiring frequent directional and speed changes.
Work in Your Comfort Zone
Whether you prefer the great outdoors or a climate-controlled workspace, you can count on the deluxe features of the Farmall compact C series tractors.
• Comfort is provided through an operator platform with proper grip that provides easy access and exit, hand and foot throttles, and an adjustable suspension seat.
• Convenience won’t be sacrificed as operators have easy access to all controls and levers, constant engine speed button for tasks that require a steady engine rpm, as well as a factory-installed loader joystcik
• Visibility is crucial so operators have unobstructed views from the tractor seat as well as well-placed controls and a two-post ROPS structure that don’t inhibit visibility
• Additional Cab amenities include a spacious cab with room to move, climate controls, and 360-degree sight lines
|MODEL||Farmall Compact 55C|
|Drive Type||Wheeled Tractor|
|Engine Power hp [ kW ]||55 |
|Maximum Power hp [ kW ]||55 |
|POWER TAKE OFF (PTO)|
|PTO Power hp [ kW ]||47 |
|Engine Make||LS Mtron|
|Transmission Type||4 synchro gears, 4 non-synchro ranges|
|Number of Forward Speeds||16|
|Number of Reverse Speeds||16|
|Maximum Speed Forward - mph (kph)||16.9 (27.2) mech; 17.9 (28.8) HST|
|Implement Pump Flow gallons (US) / min [ lt/min ]||8.2 |
|Standard Pump Pressure PSI [ bar ]|
|Number of Remote Valves||1 std; 2 opt|
|3-POINT HITCH FEATURES|
|3-Point Hitch Category||Category 1|
|3-POINT HITCH LIFT CAPACITY|
|Standard Lift Capacity 24 Inches Behind Pin lbs [ kg ]||2469 |
|Standard Lift Capacity at lift pin lbs [ kg ]||2756 |
|WHEELBASE / TRACKBASE|
|Wheelbase/Trackbase inches [ mm ]||73.2 |
|Height to Top of Cab inches [ mm ]||93.3 |
|Height of Top of ROPS inches [ mm ]||98.4 |
|Overall Width inches [ mm ]||69.1 |
