| MODEL |
BiG X 850 |
| Engine Model |
MAN V12 D 2862 |
| No. of cylinders |
12 |
| Displacement Litres |
24.24 |
| Power (to ECE R 120 standard) kW / hp |
625 / 850 |
| Max. chopping power in X Power mode kW / hp |
607 / 825 |
| Max. chopping power in Eco Power mode kW / hp |
Not Available |
| Fuel tank capacity / auxiliary tank gallons |
250 / 90 |
| Ground drive |
|
| Type |
Infinitely variable hydrostatic drive with wheel motors |
| Speed in field mode mph |
0 -14 |
| Speed in road mode mph |
0 - 25 |
| 4WD & axle separation |
Standard |
| Axles |
|
| Steering angle on rear axle Degrees |
53 |
| Rear axle suspension |
Standard - Hydraulic |
| Drivelines |
|
| Header |
Infinite variable |
| Pre-compression rollers |
Infinite variable |
| Pre-compression rollers |
|
| Pre-compression roller throat volume |
Funnel shaped |
| Service position |
Quick attach (also with head attached) |
| No. of rollers / metal detector / no. of magnet coils |
6 / Standard / 6 |
| Metal detector to shearbar distance mm |
820 (2'8") |
| Compression force / Throat opening volume |
10,141 lbs / 42 gallons |
| Chop length adjustment |
Steplessly from cab (0.1 mm increments) |
| Cutterhead |
|
| Cutterhead width / diameter mm |
800 / 660 (2'7"/ 2'2") |
| Arrangement of knives |
Chevron arranged at 11° to shearbar |
| No. of knives |
20, 28, 40 |
| Chop length range mm |
5 - 29 / 4 - 21 / 2.5 - 15 |
| Cuts / min. |
12,500 / 17,500 / 25,000 |
Stepless adjustment of drum flow /
spring-loaded drum floor |
Standard / Standard |
| Corn-Conditioner |
|
123 teeth: Straight teeth / chromed saw teeth /
tooth spacing mm |
Option / Option / 6.38 (0.25") |
144 teeth: Straight teeth / chromed saw teeth /
tooth spacing mm |
Option / Option / 5.45 (0.2") |
| 166 teeth: Saw teeth / tooth spacing mm |
Option / 4.72 (0.19") |
| Roller speed difference % |
30 |
In-cab roller gap adjustment & automatic
lubrication |
Standard |
| Roller diameter / clearance mm |
250 / 0.5 - 10 (10"/ 0.02"- 0.4") |
| Crop accelerator |
|
| Rotor diameter / Width / No. of paddles |
560 / 660 / 8 (1'10"/ 2'2"/ 8) |
| Paddle arrangement |
Centered and chevron |
| Speed rpm |
2,360 |
Stepless adjustment of the back plate /
spring-loaded back plate |
Standard / Standard |
| Spout |
|
| Rotation Degrees |
210 |
| Overhead unloading height mm |
6,000 (19'8") |
| Cross section mm |
340 x 230 (1'1.4" x 9") |
| Automatic rotation / parking function |
Standard |
| Stepless speed adjustment |
Standard |
| Drive for rotation |
Gearbox |
| Spout fully covered with wear liners |
Standard |
| Maintenance |
|
| Auto-lube system with compressor |
Standard |
| Self diagnostic system via operator terminal |
Standard |
| Cab |
|
| Air seat & passenger seat |
Standard |
| Auto climate with mobile cool box |
Standard |
| Windscreen wiper / side window wiper |
Standard |
| Dimensions |
|
| Length / Width* / Height* mm |
7,950 - 9,450 / 3,000 - 3,460 / 3,940 - 3,995
(26'1"- 31'/ 9'10"-11'4"/12'11"-13'1") |
| Base unit weight (without header)** ca. kg |
14,800 (32,628 lbs) |
Weight distribution with EasyFlow 3001
Pick-up F / H % |
55 - 45 |
Weight distribution/with EasyCollect 903
(9.00 m w.w.) F / H % |
60 - 40 |
| Tires |
|
Front axle Standard***
Option
Option
Option
Option
Option
Option |
650 / 75 R 32
710 / 75 R 34
800 / 65 R 32
900 / 60 R 32
710 / 70 R 42
800 / 70 R 38
900 / 60 R 38 |
Rear axle Standard***
Option
Option |
540 / 60 R 30
600 / 70 R 28
710 / 60 R 30 |
| Headers |
|
| EasyFlow: Pick-up |
3,000 - 3,800 (9'10"-12'6") |
| EasyCollect: Row-independent header |
7,500 / 9,000 / 10,500
(24'7" / 29'6" / 34'5") |
| Autopilot & Active ground contouring for Corn Head |
Option |
| XDisc: Direct Cut Head mm |
6,200 (20'4") |
