Features

• Tractor requirements of 40 PTO HP to 65 PTO HP and tractor weights from 3,500 US Pounds.
• 3 Flail Heads to choose from. 37” (2” Grass or 4” Rough) Cut Capacity or the 50” (2” Grass) Cut Capacity.
• 240° Head rotation on all models.
• Simple cable controlled in-cab control.
• Hydraulic break away safety mechanism built into the 1958 model, mechanical breakaway on the 1358 and the 1558.
• Machine weights from 1,338 US Pounds to 2,590 US Pounds with Oil and no cutter head.
• 3 point mounted for ease of installing the machine.

Specifications

 Model

1958

Tractor HP (Min)*

65 PTO HP*

Tractor Weight (Min)

6,500 lbs.

Tractor PTO

540 RPM

Machine Weight w/ Oil

2,590 lbs

Hydraulic System

Twin Pump

Hyd Reservoir Capacity

42 U.S. Gal.

Attachment Method

3-Point Mount

Controls

Cable Controlled

Max Reach, Horizontal

18’-8”

Up-Bank Reach

19’-4”

Down-Bank Reach

12’-8”

Max Flat Cutting Height

17’-8”

Max Cutting Height

23’-8”

Head Rotation

240°

Breakout System

Gravity Mechanical

Hydraulic Power

54 HP Total

Cable Control

Standard

Rotor Control

Cable Reversible

Approx. Shipping Weight

3,157 lbs.
