| Manufacturer |
HANGCHA GROUP CO.,LTD. |
| HCFA Model |
XF15C |
XF18C |
XF20C |
XF25C |
XF30C |
XF32C |
| Manufacturer's type designation |
CPYD15-XW81F-C |
CPYD18-XW81F-C |
CPYD20-XW71F-C |
CPYD25-XW71F-C |
CPYD30-XW71F-C |
CPYD32-XW71F-C |
| Drive: electric (battery or mains), diesel, petrol, fuel gas |
fuel gas |
fuel gas |
LPG |
LPG |
LPG |
LPG |
| Operator type: hand, pedestrian, standing, seated, order-picker |
Seated |
Seated |
Seated |
Seated |
Seated |
Seated |
| Rated capacity/rated load lb (kg) |
3000(1350) |
3500(1600) |
4000 (1800) |
5000 (2250) |
6000 (2700) |
6500 (2950) |
| Load centre distance in(mm) |
24(600) |
24(600) |
24(600) |
24(600) |
24(600) |
24(600) |
| Load distance, centre of drive axle to fork in(mm) |
15.4(391) |
15.4(391) |
16.8 (427) |
16.8 (427) |
17.7 (450) |
17.7 (450) |
| Wheelbase in(mm) |
49.2(1250) |
49.2(1450) |
57.1 (1450) |
57.1 (1450) |
57.1 (1450) |
57.1 (1450) |
| WEIGHT |
|
| Service Weight lb(kg) |
6480(2940) |
6830(3100) |
7880 (3575) |
8640 (3920) |
9570 (4340) |
9900 (4490) |
| Axle loading, laden front/rear lb(kg) |
8115/1365 (3670/620) |
9000/1330 (4095/605) |
10210/1670 (4610/765) |
11830/1810 (5350/820) |
13500/2070 (6100/940) |
14220/2180 (6450/990) |
| Axle loading, unladen front/rear lb(kg) |
2670/3810 (1210/1730) |
2600/4230 (1180/1920) |
3050/4830 (1385/2190) |
3215/5425 (1460/2460) |
3090/6480 (1400/2940) |
3200/6700 (1450/3040) |
| TYRES, CHASSIS |
|
| Tyres: solid rubber, superelastic, pneumatic, polyurethane |
Cushion |
Cushion |
Cushion |
Cushion |
Cushion |
Cushion |
| Tyre size, front |
18×6×12-1/8 |
18×6×12-1/8 |
21×7×15 |
21×7×15 |
21×8×15 |
21×8×15 |
| Tyre size, rear |
14×5×10 |
14×5×10 |
16×6×10.5 |
16×6×10.5 |
16×6×10.5 |
16×6×10.5 |
| Wheels, number front / rear (x = driven wheels) |
2×/2 |
2×/2 |
2×/2 |
2×/2 |
2×/2 |
2×/2 |
| Tread, front in(mm) |
31.9(810) |
31.9(810) |
35.4(900 |
35.4(900 |
36.2(920) |
36.2(920) |
| Tread, rear in(mm) |
32.7(830) |
32.7(830) |
36.2(920) |
36.2(920) |
36.2(920) |
36.2(920) |
| DIMENSIONS |
|
| Tilt of mast/fork carriage forward/backward (°) |
6/8 |
6/8 |
6/8 |
6/8 |
6/8 |
6/8 |
| Height, mast lowered in (mm) |
77.3(1963.5) |
77.3(1963.5) |
77.6(1970) |
77.6(1970) |
77.6(1970) |
77.6(1970) |
| Free lift in (mm) |
5.3(135) |
5.3(135) |
5.5(140) |
5.5(140) |
5.3(135) |
5.3(135) |
| Lift in (mm) |
118.1(3000) |
118.1(3000) |
118.1(3000) |
118.1(3000) |
118.1(3000) |
118.1(3000) |
| Height, mast extended in (mm) |
155.7(3955) |
155.7(3955) |
159.3(4046) |
159.3(4046) |
163.2(4145) |
163.2(4145) |
| Height of overhead guard (cabin) in (mm) |
81.7(2075) |
81.7(2075) |
83.3(2115) |
83.3(2115) |
83.3(2115) |
83.3(2115) |
| Seat height relating to SIP in (mm) |
38.6(980) |
38.6(980) |
40.2(1020) |
40.2(1020) |
40.2(1020) |
40.2(1020) |
| Coupling height in (mm) |
10.2(260) |
10.2(260) |
11.8(300) |
11.8(300) |
11.8(300) |
11.8(300) |
| Overall length in (mm) |
118.7(3016) |
120(3046) |
132.5(3367) |
135.1(3432) |
138(3505) |
139(3530) |
| Length to face of forks in (mm) |
82.5(2096) |
83.7(2126) |
90.4(2297) |
93(2362) |
95.7(2435) |
96.7(2460) |
| Overall width (without backrest) in (mm) |
38(964) |
38(964) |
42.5(1080) |
42.5(1080) |
44.2(1123) |
44.2(1123) |
| Fork dimensions in (mm) |
1.4×3.9×36.2(35×100×920) |
1.4×3.9×36.2(35×100×920) |
1.6×4.8×42(40×122×1070) |
1.6×4.8×42(40×122×1070) |
1.8×4.8×42(45×122×1070 |
1.8×4.8×42(45×122×1070 |
| Fork carriage DIN 15 173 --- ISO 2328, class/type A,B |
Class A |
Class A |
Class A |
Class A |
Class A |
Class A |
| Backrest width in (mm) |
35.4(900) |
35.4(900) |
43 (1094) |
43 (1094) |
45.5 (1156) |
45.5 (1156) |
| Fork-carriage width in (mm) |
37.6(954) |
37.6(954) |
40.9(1038) |
40.9(1038) |
43.3(1100) |
43.3(1100) |
| Distance between fork-arms in (mm) |
8.9-36.2(226-920) |
8.9-36.2(226-920) |
8.9-39.7(226-1008) |
8.9-39.7(226-1008) |
9.9-42.6(252-1082) |
9.9-42.6(252-1082) |
| Ground clearance, laden, below mast in (mm) |
3.3(83.5) |
3.3(83.5) |
3.5(90) |
3.5(90) |
3.5(90) |
3.5(90) |
| Ground clearance, centre of wheelbase in (mm) |
3.7(93.5) |
3.7(93.5) |
5.1(130) |
5.1(130) |
5.1(130) |
5.1(130) |
| Aisle width for pallets 1000 x 1200 crossways in (mm) |
132.7(3371) |
133.9(3401) |
139.8(3552) |
142.4(3617) |
145(3685) |
146.1(3710) |
| Aisle width for pallets 800 x 1200 lengthways in (mm) |
140.6(3571) |
141.8(3601) |
147.7(3752) |
150.3(3817) |
153(3885) |
153.9(3910) |
| Turning radius in (mm) |
70.1(1780) |
71.3(1810) |
75.8(1925) |
78.3(1990) |
80.3(2035) |
81.1(2060) |
| Minimum plvoting distance in (mm) |
18.9(481) |
18.9(481) |
21.2(539) |
21.2(539) |
21.2(539) |
21.2(539) |
| Performance Data |
|
| Travel speed, laden/unladen mph (km/h) |
11.2/11.5 (18/18.5) |
11.2/11.5 (18/18.5) |
10.9/11.5 (17.5/18.5) |
10.9/11.5 (17.5/18.5) |
10.9/11.5 (17.5/18.5) |
10.9/11.5 (17.5/18.5) |
| Lift speed, laden/unladen ft/min (m/s) |
110/118 (0.56/0.60) |
110/118 (0.56/0.60) |
122/128 (0.62/0.65) |
122/128 (0.62/0.65) |
98.4/104.3 (0.50/0.53 |
98.4/104.3 (0.50/0.53) |
| Lowering speed, laden/unladen ft/min (m/s) |
88.6/98.4 (0.45/0.50) |
88.6/98.4 (0.45/0.50) |
88.6/98.4 (0.45/0.50) |
88.6/98.4 (0.45/0.50) |
88.6/98.4 (0.45/0.50) |
88.6/98.4 (0.45/0.50) |
| Drawbar pull, laden/unladen N |
16500/8500 |
16500/8500 |
23000/9000 |
23000/9000 |
23000/9000 |
23000/9000 |
| Gradeability, laden/unladen % |
25/20 |
25/20 |
30/20 |
30/20 |
25/20 |
25/20 |
| Service brake |
Hydraulic |
Hydraulic |
Hydraulic |
Hydraulic |
Hydraulic |
Hydraulic |
| Parking brake |
Mechnical |
Mechnical |
Mechnical |
Mechnical |
Mechnical |
Mechnical |
| Combustion-engine |
|
| Engine manufacturer/type |
GCT GK21 LPG CERT |
GCT GK21 LPG CERT |
GCT GK25 LPG CERT |
GCT GK25 LPG CERT |
GCT GK25 LPG CERT |
GCT GK25 LPG CERT |
| Engine power hp (kW) |
40 |
40 |
61.4(45.8) |
61.4(45.8) |
61.4(45.8) |
61.4(45.8) |
| Rated speed r/min (-)/(cm ) |
2700 |
2700 |
2700 |
2700 |
2700 |
2700 |
| Number of cylinders/displacement |
4/2065 |
4/2065 |
4/2488 |
4/2488 |
4/2488 |
4/2488 |
| Generator |
12 |
12 |
12 |
12 |
12 |
12 |
| Vehicle electrical system voltage |
12 |
12 |
12 |
12 |
12 |
12 |
| Battery voltage/nominal capacity V/Ah |
12/60 |
12/60 |
12/60 |
12/60 |
12/60 |
12/60 |
| Rated torque N·m/r/min |
150/2000 |
150/2000 |
187/1600 |
187/1600 |
187/1600 |
187/1600 |
| Transmissions Manufacturer |
China |
China |
China |
China |
China |
China |
| Transmissions Type |
Powershift |
Powershift |
Powershift |
Powershift |
Powershift |
Powershift |
| Stage FWD/RVS |
1/1 |
1/1 |
1/1 |
1/1 |
1/1 |
1/1 |
| Addition data |
|
| Operating pressure for attachments psi (MPa) |
2103(14.5) |
2538(17.5) |
2538(17.5) |
2538(17.5) |
2538(17.5) |
2538(17.5) |
| Hydraulic Tank - capacity (drain & refill) gal (liter) |
8.5(32) |
8.5(32) |
11(42) |
11(42) |
11(42) |
11(42) |
| Fuel tank capacity gal (liter) |
NA |
NA |
NA |
NA |
NA |
NA |
